The glow switch Preheating status in the combustion chamber is shown. The decomp control The compression of 31 < and the engine goes through the decomp. Use in the following case. (1) When starting at the time of the cold season cold sake (2) In case of the battery charging rate lack [ Note ] . After decomp use, repel a control surely before hand. When neglecting, it becomes in the compression leakage boiling of an engine and the engine output doesn't come out. The turn signal switch (1) When operating to the direction of the turning-over, the turn signal lamp blinks. (2) If the turning-over ends, let's return a switch to Central. The oil lamp It is the oil pressure warning light which lights up when the lubrication system is a malfunction while the engine turns. It lights up when making main switch "O" in the engine not running and it goes out when starting. At the time as it lit up, check the engine oil quantity. The charge lamp It is the charge warning light which lights up when the charging system is a malfunction while the engine turns. It lights up when making a battery switch "O" in the engine not running and it goes out when starting. [ Note ] . Only by the easy checker, the daily inspection check finishing. surely. ( Page 27 everyday check-up reference ) The tractor meter 9.4 Cn0 The horn buttons The horn sounds when making a battery switch the position of "O" and pressing a horn buttons. The elapsed time integrator The time when using an engine in the rated-revolution
