DAILY CHECK For your own safety and maximum service life of the machine, make a through daily inspection before operating the machine to start the engine. CAUTION To avoid personal injury:• Be sure to check and service the tractor on a flat place with the engine shut off and the parking brake "ON". Walk Around Inspection Look around and under the tractor for such items as loose bolts, trash build-up, oil or coolant leaks, broken or worn parts.|Checking and Refueling CAUTION To avoid personal injury:• Do not smoke while refueling. Be sure to stop the engine before refueling.1. Check the amount of fuel by fuel gauge.2. When the fuel warning indicator lights up, it is time to add fuel.3.NOTEark the tractor at a flat ground in order to check this indicator. Use grade No.2-Diesel fuel at temperatures above-10°C (14°F). Use grade No.1-Diesel fuel at temperatures below-10°C (14°F). M4900-M5700M6800S M8200-M9000F-10385В(1) Fuel tank capM4900-M5700-M6800SM8200-M9000IMPORTANT:Fuel tank capacity65 L (17.2 U.S.gals.)90 L (23.8 U.S.gals.) Do not permit dirt or trash to get into the fuel system. Be careful not to let the fuel tank become empty, otherwise air will enter the fuel system, necessitating bleeding before next engine start. Be careful not to spill during refueling. If a spill should occur, wipe it off at once, or it may cause afire. To prevent condensation (water) accumulation in the fuel tank, fill the tank before parking overnight.NOTE:No.2-D is a distillate fuel of lower volatility for engines in industrial and heavy mobile service.Grade of Diesel Fuel Oil According to ASTM D975(SAE J313 JUN87)F-11845A(1) Fuel tank cap Flash Point°C (°F)Water and Sediment, volume%CarbonResidue on,10 percent Residuum, % Ash, weight % Min อ Max Max Max52 (125) 0.05 0.35 0.01DistillationTemperatures,°C (°F) 90%PointViscosity Kinematic cSt or mm²/sat 40°CViscosity Say bolt, SÚS at100°FSulfur, weight % Copper strip Corro Cetane Number sion Min Max Min Max Min Max Max Max Min282(540)338(640) 1.9 4.1 32.6 40.1 0.50 No.3 40
