Ο Fig.No. Represents No. corresponding to each group name.② L.No.(location No.)Substitute for conventional page numbering. Left-hand pages of the parts list arenumbered in XXX-L, and the right-hand pages in XXX-R.The location Nos. are also used in numerical index at the end of parts list.3 Components. The components of an assembly are identified by a bracket of dotted lines.4 Point. Indicates that the parts is not sold independently.The assembly (REF. No. 010) containing the part needs to be ordered.5 REF.No. Reference numbers are assigned to parts in the illustration. The code number of apart in the illustration can be identified by referring to the same reference number in6 Model nameS.No. (serial No.)8 I.C.......(interchangeability)Example-1........6Example-2.Example-3the parts list.The name of the basic model is indicated in this column. Other applicable modelsare indicated on the "REMARKS" column.Indicates a group of serial numbers to which a design change is applied.Indicates the interchangeability of parts due to design change.☐☐ indicates that a new part can replace an old part, but not vice versa.15800-0000-0 is applicable to the first serial number to S.No. 15000.15800-0000-2 is applicable to the first serial number and above.✗ indicates that the new and old parts are not interchangeable.15800-1000-0 is applicable to the first serial number to S.No. 15000.15800-1000-2 is applicable to S.No. 15001 and above.Lindicates that the new and old parts are interchangeable. Both 15800-2000-0and 15830-2000-0 are applicable to the first serial number and above.REMARKS. In this column, enter other applicable model names, dimensions and other specialitems.Specifications....... (for sister The types and destinations of sister models are indicated. These indicationsmodels)given to tell their relevant pages in this book.areThe symbols, A and CA in the "REMARKS" column or "HEADING" show the modelsas to the following types.[SYMBOL) (TYPE)A............... RC54-71B RC60-71B-USA SPEC.CA ............ RC54-71B RC60-71B-CANADA
