Fig. No. Represents No. corresponding to each group name.② Specifications........ The types and destinations of sister models are indicated. These indications are given to(for sister models) tell their relevant pages in this book.3 Components......... The components of an assembly are identified by a bracket of dotted lines.4 Point Indicates that the parts is not sold independently.The assembly (Ref.No.050) containing the part needs to be ordered.⑤REF. NO.... Reference numbers are assigned to parts in the illustration. The code number of a part inthe illustration can be identified by referring to the same reference number in the parts list.6 Model name........ The name of the basic model is indicated in this column. Other applicable models areindicated on the "REMARKS" column 9.7 S. No. Indicates a group of serial numbers to which a design change is applied.(serial No.)Engine Serial No.87 J 000187 KA001ALower 4 digits in Numerals or Alphabetical letter (A to Z) and Numerals (start 0001 to maxZ999).5th digit Alphabetical letter (Month of manufacture).Month 2 3 4 5 6 7 8 9 10 11 12A,B C.D E.F G.H J,K L.M N.P Q,R S.T UV W.X Y.Z6th digit.... Numerals or Alphabetical letter (Year of manufacture).Year 1998 1999 2000 01 02 03 04 05 06 07 08 09 10 11W X Y 1 2 3 4 5 6 7 8 9 A BYear 12 13 14 15 16 17 18 19 20 21 22 23 24 25C D E F G H ال K L M N P R S7th digit Numerals or Alphabetical letter (The factory line identifying).Identifying 1 2 3 4 5 6 7 8 A B(8 I. C. Indicates the interchangeability of parts due to design change.(interchangeability)Example-1 ......indicates that a new part can replace an old part, but not vice versa.15800-0000-0 is applicable to the first serial number to S. No. 15000.15800-0000-2 is applicable to the first serial number and above.Example-2.......... ≠ indicates that the new and old parts are not interchangeable.15800-1000-0 is applicable to the first serial number to S. No. 15000.15800-1000-2 is applicable to S. No. 15001 and above.Example-3 → indicates that the new and old parts are interchangeable. Both 15800-2000-0 and15830-2000-0 are applicable to the first serial number and above.9 REMARKS 1... In this column, enter other applicable model names, dimensions and other special items.The following symbols and abbreviations are used throughout this book.29* 12.00-15 ... Tire size sq.m ... m² sq.mm ... mm²cu.m... m³ cu.mm... mm³ D... Diameter L... LengthSTD... Standard SET... Set sale T... TeethW/G No.... Whole goods number.OLD... Old parts, old shapes or old modelsNEW... New parts, new shapes or new models
